Frontier LP7700 - No. 01552 the Paper in the Colorimeter Is too Short. It Cannot be Measured

Attention message: Colorimeter
1/3
4. Troubleshooting
41550
41550
Attentio n message: Colo rimeter
No. 01552
The paper in the Colorimeter is too short. It cannot be measured.
Attention message release
YES
Condition
NOTE
• See the setup print color measuring operation flow. ☞56610
Check Point
Diagnosis
NOTE
• To access the wiring diagrams, click Wiring diagrams in Bookmarks.
Suffix number Condition
00001 While feeding test print in the colorimeter unit, paper sensor 1 turned DARK. After that, paper sensor 1 turned
LIGHT before advancing a specified amount of paper.
00002 While feeding test print in the colorimeter unit, paper sensors 1 and 2 turned DARK. After that, paper sensor 1
turned LIGHT before advancing a specified amount of paper.
1 Check that a short test print has not been inserted.
2 Carry out each correction via Colorimeter Unit Adjustment.
Failed part Manual No.
Paper sensor 1 or 2
☞63318
Paper advance motor
Processor control PCB ☞66200
Processor I/O PCB 2
☞66211
Colorimeter unit ☞27460
