Periodically replaced parts
1/6
8. Appendix
80110
80110
Periodi cally r eplaced parts
List of maintenance/periodically replaced parts/consumable parts
The list below shows maintenance items and parts required to be performed or replaced by user or service personnel to keep the system
quality.
Check the actual processing hours and number of prints using the hour meter and the print counter.
IMPORTANT
• For the maintenance parts, regularly check them and replace them if necessary.
Some parts need to be replaced according to the processing time or the number of processed prints. The replacement
timing varies depending on the operating condition of the system.
Since the replacement timing is the rough standard, you need not necessarily replace the parts at the specified timing.
• For the periodically replaced parts, replace them when the processing time or the number of prints processed reaches the
specified value regardless of the condition of the parts.
• The numerical values below do not show any warranty period.
NOTE
• The hour meter and the print counter are optional on the systems which are to be shipped outside Japan.
!
!!
! List of maintenance
For the procedure of maintenance by users, refer to Maintenance Manual.
Printer section (common)
Processor section (PP7500/PP7600/QSS-3701/3702[N[ [SM] [J[ [F], PP-7900/QSS-3703 [N[ [SM] [J[ [F])
Parts or checking items Description for maintenance Part No. Timing/Standard
replacement
timing
Quantity
Paper supply unit
Manual cutter
Check whether it cuts well and replace it
if dull.
-As needed 1
Paper supply unit
Paper cutter unit
Check whether it cuts well and replace it
if dull.
Maintenance parts
Replace it approx. every 1,500,000 prints
by the print counter.
H076033 1,500,000 prints 1
CVP unit
Dot head unit
Check the printing condition and replace
it if any dots are missing. (This is a
maintenance part. Replace it when the
print counter reaches approximately
2700000.)
I086167 2,700,000 prints 1
Parts or checking items Description for maintenance Part No. Timing/Standard
replacement
timing
Quantity
Upper guide
Turn roller (EPDM) (No. 2
upper guide)
Check its damage or wear. If it is
damaged or worn, replace it with a new
one.
Check it every six months after three
years has passed. If necessary, replace it
with a new one.
A087423 Three years • [F]: 1
• [N]: 3
• [SM][J]: 3
B023926 • [F]: 1
• [N]: 0
• [SM][J]: 0
B024363 • [F]: 1
• [N]: 0
• [SM][J]: 0
B024364 • [F]: 1
• [N]: 0
• [SM][J]: 0
