Frontier LP7700 - Removing each Cover (Processor Section) [Print Sorter Unit (6-Inch Type, 17;14 Orders)] [N] [Sm

3/7
2. Replacement and adjustment of parts
20020
20020
Removing covers
Removing each cover (Processor section) [print sorter unit (6-inch type,
17/14 orders)] [N] [SM]
Description for each specification
In this section, the location of information varies depending on the specification. See below for the description for each specification.
Reference
☞Removing each cover (Processor section) [print sorter unit (6-
inch type, 17/14 orders)] [J]
☞Removing each cover (Processor section) [print sorter unit (6-
inch type, 17/14 orders)] [F]
Remove screws with this mark.
Loosen screws with this mark.
11
10
9
8
7
6
5
4
3
2
1
G085342
