4. Troubleshooting
46100
46100
Error message: Printer 2
No. 06195
Paper did not load. Paper Magazine A2
Error message release
YES
Condition
Check Point
Diagnosis
$ Symptoms due to connection failure of wiring/symptoms resulted from blowout of fuse
NOTE
• To access the wiring diagrams, click Wiring diagrams in Bookmarks.
Suffix number Condition
00001 Even though a specified length of paper is advanced after paper loading started, paper end sensor A2 does not
turn DARK during setup or printing for mechanical adjustments.
00002 Even though a specified length of paper is advanced after paper end sensor A2 turns LIGHT, the loading sensor
does not turn DARK.
1 Check that the paper is correctly inserted into the paper magazine.
2 Clean the advance roller.
Advance failure Manual No.
Paper magazine motor A2 ☞ 63051
Paper supply motor A2
☞63055
Paper supply motor A ☞63060
Printer I/O PCB 2 ☞66030
Quad magazine PCB
☞66055
Printer control PCB ☞66000
Detection failure (paper end sensor) Manual No.
Paper end sensor A2
☞63051
Quad magazine PCB ☞66055
Printer control PCB ☞66000
Detection failure (paper loading sensor) Manual No.
Paper loading sensor ☞66030
Printer I/O PCB 2
Printer control PCB
☞66000
Symptoms due to the wiring connection failure Symptoms of fuse blowout
☞4202 − ☞4252
