3. Mode
35320
6/7
35320
Maintenance
Output Check (Processor) [J]
Description for each specification
For the specifications other than [F] specification, this section only gives description that differs from that for [F] specification. See below
for the description for each specification.
!
!!
! Processor Section 1[J]
!
!!
! Processor Section 2[J]
!
!!
! Tablet Replenishment Section 1[J]
!
!!
! Tablet Replenishment Section 2[J]
Reference
☞Output Check (Processor) [N] ☞Output Check (Processor) [SM] ☞Output Check (Processor) [F]
No. Display Status
1 Drive Motor + Drive Cooling Fan Press Execute to start, and Cancel to stop.
2 CD Heater Press Execute to start, and Cancel to stop.
3 BF Heater Press Execute to start, and Cancel to stop.
4 STB Heater Press Execute to start, and Cancel to stop.
5 CD Cooling Water Solenoid Valve Press Execute to start, and Cancel to stop.
6 BF Cooling Water Solenoid Valve Press Execute to start, and Cancel to stop.
7 STB Cooling Water Solenoid Valve Press Execute to start, and Cancel to stop.
8 Tank Cooling Fan Press Execute to start, and Cancel to stop.
9 Exhaust Fan Press Execute to start, and Cancel to stop.
10 Processor Condition Lamp (Green) Press Execute to turn ON, and Cancel to turn OFF.
11 Processor Condition Lamp (Red) Press Execute to turn ON, and Cancel to turn OFF.
12 Signal Lamp Press Execute to turn ON, and Cancel to turn OFF.
13 Control Strip Advance Motor • Execute:Control Strip Advance Motor starts.
• Cancel:Control Strip Advance Motor does not stop.
No. Display Status
1 CD Water Supply Pump Press Execute to start, and Cancel to stop.
2 S -> B Replenishment Pump Press Execute to start, and Cancel to stop.
3 STB Water Supply Pump Press Execute to start, and Cancel to stop.
4 Cleaning Pump Press Execute to start, and Cancel to stop.
No. Display Status
1 CD Operation Lamp Press Execute to start, and Cancel to stop.
2 BF Operation Lamp Press Execute to start, and Cancel to stop.
3 STB Operation Lamp Press Execute to start, and Cancel to stop.
4 Elevator Motor (Up) Press Execute to start, and Cancel to stop. Temporarily stops if
detected by the elevator middle sensor. When two seconds passes,
starts again. When detected by the elevator upper sensor, stops.
5 Elevator Motor (Down) Press Execute to start, and Cancel to stop. Stops when detected by
the elevator lower sensor.
6 STB Tablet Conveyor Motor Press Execute to operate once.
No. Display Status
1 CD Drum Motor (Forward) Press Execute to operate once.
2 CD Drum Motor (Reverse) Press Execute to operate once.
