4. Troubleshooting
46200
18/21
46200
Error message: Printer 3
No. 06227
Paper did not load. Paper Magazine A
No. 06228
Paper did not load. Paper Magazine B
No. 06229
Could not load the paper. Paper Magazine C
No. 06230
Paper did not load. Paper Magazine A2
No. 06231
Paper did not load. Paper Magazine A
Error message release
YES or Forced Output
• YES
1. Click YES.
The error display is closed and paper loading starts.
• Forced Output
1. Click Forced Output.
For the double magazine specification, No.01121 Which paper magazine would you like to print with? is shown.
For the triple magazine specification, No.01122 Which paper magazine would you like to print with? is shown.
For the quad magazine specification, No.01123 Which paper magazine would you like to print with? is shown.
2. Check the print.
If white margin is on the print, cut the margin.
NOTE
• This error occurs only when processing normal prints.
Condition
Check Point
Diagnosis
Error message No. Condition
No. 06227-00001 The paper end sensor A does not turn DARK when the paper from paper magazine A of the triple
magazine is loaded.
No. 06228-00001 The paper end sensor B does not turn DARK when the paper from paper magazine B is loaded.
No. 06229-00001 The paper end sensor C does not turn DARK when the paper from paper magazine C is loaded.
No. 06230-00001 The paper end sensor A2 does not turn DARK when the paper from paper magazine A2 is loaded.
No. 06231-00001 The paper end sensor A does not turn DARK when the paper from paper magazine A of the quad
magazine is loaded.
1 Check that the paper is correctly inserted into the paper magazine.
2 Clean the advance roller.
Detection failure (double magazine) Manual No.
Paper end sensor B Paper end sensor C
☞63051
Printer I/O PCB 1
☞66020
Printer I/O PCB 3 ☞66040
Printer control PCB
☞66000
Detection failure (triple magazine) Manual No.
Paper end sensor A ☞63051
