4. Troubleshooting
46200
46200
Error message: Printer 3
$ Symptoms due to connection failure of wiring/symptoms resulted from blowout of fuse
NOTE
• To access the wiring diagrams, click Wiring diagrams in Bookmarks.
Triple magazine PCB
☞66050
Printer control PCB ☞66000
Detection failure (quad magazine) Manual No.
Paper end sensor A Paper end sensor A2
☞63051
Quad magazine PCB ☞ 66055
Printer control PCB ☞66000
Advance failure Manual No.
Paper magazine motor A Paper magazine motor A2 ☞63051
Paper magazine motor B Paper magazine motor C
Paper supply motor A Paper supply motor B/C
☞63060
Printer I/O PCB 1 ☞66020
Printer I/O PCB 2 ☞66030
Printer control PCB
☞66000
Triple magazine PCB ☞66050
Quad magazine PCB ☞ 66055
Symptoms due to the wiring connection failure Symptoms of fuse blowout
☞4202 −−
Detection failure (triple magazine) Manual No.
