Frontier LP7700 - Error message: Processor 1

Error message: Processor 1
1/14
4. Troubleshooting
45500
45500
Error messag e: Proces sor 1
No. 05500
The processing solution temperature is above the safety range. P1
No. 05501
The processing solution temperature is above the safety range. P2
No. 05502
The processing solution temperature is above the safety range. PS
Alarm release
NO
Error message release
YES
Condition
Check Point
Diagnosis
NOTE
• To access the wiring diagrams, click Wiring diagrams in Bookmarks.
Error message No. Condition
No. 05500-00000 The P1 processing solution temperature exceeds the safety range (setting temperature + 1°C) after the
temperature adjustment is finished. (P1 thermosensor)
No. 05501-00000 The P2 processing solution temperature exceeds the safety range (setting temperature + 3°C) after the
temperature adjustment is finished. (P2 thermosensor)
No. 05502-00000 The PS processing solution temperature exceeds the safety range (setting temperature + 3°C) after the
temperature adjustment is finished. (PS thermosensor)
NOTE
• There is a specific process specification whose safe range of PS is the setting temperature + 7°.
1 Confirm that the value measured via Thermosensor Calibration is correctly entered.
2 Check whether the tank cooling fans (FAN 1 to 3) operate normally.
For cooling failure Manual No.
Cooling fan ☞63290
Processor I/O PCB 1
☞66210
Processor control PCB ☞66200
When temperature is incorrectly detected Manual No.
Processor control PCB
☞66200
Thermosensor
☞63290
