Frontier LP7700 - Input Check (Processor) [F

Maintenance
1/9
3. Mode
35220
35220
Input Check (Processor) [F]
Bringing up the display
Maintenance → Extension → Maintenance → Input Check → Processor
Description for each specification
For the specifications other than [F] specification, this section only gives description that differs from that for [F] specification. See below
for the description for each specification.
!
!!
! Input Check
!
!!
! 1 (for each specification)
*1. If the processable level sensors for each processing solution are OFF, the system stops printing to prevent the time that paper is soaked from
becoming short and printing quality from degrading.
*2. It may take one minute for communicating between the processor control PCB and control strip unit.
!
!!
! 2 (for each specification)
Reference
☞Input Check (Processor) [N] ☞Input Check (Processor) [SM] ☞Input Check (Processor) [J]
Item Specification Reference
Processor Section F
☞1 (for each
specification)
☞2 (for each
specification)
☞3 (for each
specification)
☞3 (for each
specification)
N
☞1 [N] ☞2 [N]
SM
☞1 [SM] ☞2 [SM] ☞3 [SM] ☞4 [SM]
J ☞1 [J] ☞2 [J] ☞Tablet Replenishment Section [J]
Dryer Section Common ☞ Dryer Section (common to all specifications)
Order Classification
Section
☞Order Classification Section (common to all specifications)
Colorimeter Unit
☞Colorimeter Unit (common to all specifications)
No. Display Status
1 ON/OFF Processing Solution Level OFF ☞No. 05508 occurs.
2 ON/OFF Processing Solution Safety Thermostat ON Normal
2 ON/OFF Interlock Switch (Processor Top Cover) ON When the cover is closed.
3 ON/OFF P1 Processable Solution Level OFF
☞No. 05916[F]occurs.
*1
4 ON/OFF P2 Processable Solution Level ☞No. 05917[F]occurs.
*1
5 ON/OFF PS1 Processable Solution Level ☞No. 05918[F]occurs.
*1
6 ON/OFF PS2 Processable Solution Level ☞No. 05919[F]occurs.
*1
7 ON/OFF PS3 Processable Solution Level ☞No. 05920[F]occurs.
*1
8 ON/OFF PS4 Processable Solution Level ☞No. 05921[F]occurs.
*1
9 ON/OFF P1 Effluent Float Switch ON When the effluent is full.
10 ON/OFF P2 + PS Effluent Float Switch ON
11 CLOSE/OPEN Starter Jumper Setting CLOSE When the jumper of the processor relay PCB is
connected
12 ON/OFF Rack Stopper Sensor ON When the rack stopper is set.
13 ON/OFF Control strip holder detection switch
*2
ON When the control strip holder is detected
No. Display Status
1 ON/OFF Control strip processing complete.
*3
• ON: Advancing the control strip is completed.
• OFF: Advancing the control strip is not completed.
3 ### Pump Rotation Detector When an error occurs.
*1
4 50/60 Power Supply Frequency (Hz) Displays the frequency.
