4. Troubleshooting
45500
5/14
45500
Error message: Processor 1
No. 05508
The processing solution level is too low.
Alarm release
NO
Error message release
YES
Condition
NOTE
• If the processing solution level detector of the processing solution float switch turns off, all the processing solution heaters and
circulation pumps turn off.
Check Point
Common to all specifications
Diagnosis
Common
[F]
[N]
[SM]
Suffix number Condition
00000 The processing solution level detectors of the processing solution float switches (P1, P2 and PS) turned off.
1 Check if the processing solution is leaking from the tank.
2 Clean the replenishment pump, strainer units of water supply pump or a hose. Check the output amounts.
3 Check if the float of the processing solution float switch moves up and down smoothly.
When the level is incorrectly detected Manual No.
Processing solution float switch ☞63290
Processor relay PCB ☞66220
Processor control PCB
☞66200
Processor I/O PCB 1 ☞66210
Processor power supply 2 ☞67400
When the solution is insufficiently added Manual No.
P1R Replenisher Pump
P2RA Replenisher Pump
P2RB Replenisher Pump
☞63290
F replenishment I/O PCB ☞66800
Processor control PCB ☞66200
When the solution is insufficiently added Manual No.
Replenisher pump ☞ 63290
Refilling water pump ☞ 63290
Processor control PCB
☞66200
Processor I/O PCB 1
☞66210
When the solution is insufficiently added Manual No.
Replenisher pump
☞63290
Water Supply Pump ☞63290
