3. Mode
35220
2/9
35220
Maintenance
*1. Displays OK if all circulation pumps are normally rotating.
When an error occurs, displays the circulation pump at which an error is occurring. (P1, P2, PS1, PS2, PS3, PS4)
If the errors occur at two or more pumps simultaneously, the error is shown in the order from P1.
*2. Displays only when the digital flowmeter is registered as options.
*3. It may take one minute for communicating between the processor control PCB and control strip unit.
!
!!
! 3 (for each specification)
!
!!
! Dryer Section (common to all specifications)
!
!!
! Order Classification Section (common to all specifications)
5 #.## P1 Flow Amount Displays the P1 circulation amount.
*2
6 ### Drive Motor Revolution Count
No. Display Status
1 ON/OFF P1R (Upper) Replenishment Solution Level
Sensor
OFF When the solution level is too low.
2 ON/OFF P1R (Lower) Replenishment Solution Level
Sensor
OFF
3 ON/OFF P2RA (Upper) Replenishment Solution Level
Sensor
OFF
4 ON/OFF P2RA (Lower) Replenishment Solution Level
Sensor
OFF
5 ON/OFF P2RB (Upper) Replenishment Solution Level
Sensor
OFF
6 ON/OFF P2RB (Lower) Replenishment Solution Level
Sensor
OFF
7 ON/OFF PSR (Upper) Replenishment Solution Level
Sensor
OFF
1 ON/OFF PSR (Lower) Replenishment Solution Level
Sensor
OFF
2 ON/OFF Interlock Switch (Replenisher Section Door) ON When the cover is closed.
3 DARK/LIGHT Replenisher Cartridge Set Sensor DARK When the replenish cartridge is set
4 DARK/LIGHT Replenisher Cartridge Position Sensor (Upper) DARK When the replenish cartridge is in the upper
position
5 DARK/LIGHT Replenisher Cartridge Position Sensor (Lower) DARK When the replenish cartridge is in the lower
position
6 #.# Environment Temperature Displays the temperature and humidity in the place where
the temperature and humidity sensor is attached.
See
☞63280 for the installation position of the
temperature and humid sensor.
7 #.# Environment Humidity
No. Display Status
1 ON/OFF Dryer Safety Thermostat OFF When the dryer safety thermostat is turned off.
2 ON/OFF Interlock Switch (Dryer Cover) ON When the cover is closed.
3 DARK/LIGHT Print Sensor (Left) DARK Paper is detected.
4 DARK/LIGHT Print Sensor (Center) DARK Paper is detected.
5 DARK/LIGHT Print Sensor (Right) DARK Paper is detected.
6 DARK/LIGHT Dryer Lane Select Sensor DARK Paper is detected.
No. Display Status
1 DARK/LIGHT Sorter Home Sensor DARK Home position: Print receiving position
2 DARK/LIGHT Print Full Sensor DARK Paper is detected.
3 ON/OFF Manual Sorter Switch ON When the switch is pressed.
4 DARK/LIGHT Conveyor Unit Sensor DARK When the conveyor unit is set.
No. Display Status
