5. Operation sequence
55100
4/4
55100
Paper advance operation
Conditions other than above
Goes to Step 14.
13. Performs magazine initial operation.
Magazine initial operation is the operation that rewind the paper until the paper end sensor is not detected, and next advance
the paper to the position where it passed through the paper loading sensor again.
• Paper magazine motor A/B/C: ON/OFF
• Paper supply motor A/B/C: ON/OFF
If paper end sensor A/A2/B/C cannot detect the papers in rewinding paper and in re-advancing, and if
paper loading sensor cannot detect the papers in re-advancing
• ☞ No. 06012-00002
Paper did not load. Paper Magazine A
•
☞No. 06201-00002
Paper did not load. Paper Magazine A
•
☞No. 06013-00002
Paper did not load. Paper Magazine B
•
☞No. 06012-00002
Could not load the paper. Paper Magazine C
14. The paper is advanced for the paper length.
• Paper magazine motor A/A2/B/C: ON/OFF
• Paper supply motor A/A2/B/C: ON/OFF
• Paper advance motor 1: ON/OFF
IMPORTANT
• Arm unit 1 advances the paper at the same speed of loading.
☞55200
15. The paper is cut.
• Cut motor: ON/OFF
When cutting is not completed:
• ☞ No. 06016-00001
Paper Cutter operation error.
16. Paper is advanced to Arm unit 1 receiving position.
• Paper advance motor 1: ON/OFF
When arm unit 1 is not on standby in receiving position
• The paper stays at the paper standby position until arm unit 1 comes down to its receiving position.
17. Loading and cutting are completed.
