Periodically replaced parts
!
!!
! List of periodically replaced parts
!
!!
! List of consumable parts
!
!!
! CVP unit (option)
Upper guide
Bearing (upper guides No.3 to 6)
Check its damage or wear. If it is
damaged or worn, replace it with a new
one.
Check it every six months after three
years has passed. If necessary, replace it
with a new one.
A032741 Two years 4 each
A032742 4 each
Upper guide
Gear (upper guides No. 5 to 8)
A050698 1 each
Upper guide
Turn roller (squeegee roller)
Check its damage or wear. If it is
damaged or worn, replace it with a new
one.
Check it every six months after three
years has passed. If necessary, replace it
with a new one.
A087419 Three years 2
Upper guide
Bearing (squeezee roller)
Check its damage or wear. If it is
damaged or worn, replace it with a new
one.
Check it every six months after three
years has passed. If necessary, replace it
with a new one.
A032741 Two years 4
A032742 4
Upper guide
Gear (squeegee roller)
A050698 1
Processing rack section
Gear
Check its damage or wear. If it is
damaged or worn, replace it with a new
one.
Check it every six months after three
years has passed. If necessary, replace it
with a new one.
A050696 Two years 6
A050695 6
Processing rack section
Roller holder
A051198 6
Part name Part No. Quantit
y
Recommended timing of replacement
Calibration plate unit B Z026559 1 2 years (When the performance of calibration plate
falls due to the storage status, it is necessary to
replace the plate even if it is before from the
recommended timing of replacement)
Cleaning sheet H089041 1 If the surface of cleaning sheet becomes dirty and
adhesive power is lost, change it with a new sheet.
Replenisher section [SM]
Probe (2) assembly (CD-C only)
A054659 1 One year
Replenisher section [SM]
Probe (1) assembly (Except CD-C)
A054658 5 One year
Replenishment pump [SM]
Poppet valve (STB only)
I091040 2 One year
Part name Part No. Quantity Reference
value of
consumption
Reason for maintenance/replacement
Ink ribbon cassette H086044 1 100000 prints If it runs out of ink, back print may not be
printed normally.
Parts or checking items Description for maintenance Part No. Timing/Standard
replacement
timing
Quantity
