7/15
4. Troubleshooting
46000
46000
Error message: Printer 1
No. 06073
Synchronous Sensor error.
Error message release
NO
Condition
Diagnosis
IMPORTANT
• The output lines of R, G and B from the laser control PCB to laser unit are separate.
• Carry out R Laser Output ON, G Laser Output ON and G Laser Output ON of Output Check → Printer → Exposure
Engine Section. If the results are as same as shown below, each laser is normal.
☞35310
• Laser Synchronous Sensor:Synchronous
• Polygon Mirror Frequency:2043±7
• If all lasers are abnormal, the synchronous sensors (in the laser unit) may be defective.
$ Symptoms due to connection failure of wiring/symptoms resulted from blowout of fuse
NOTE
• To access the wiring diagrams, click Wiring diagrams in Bookmarks.
Suffix number Condition
00001 The R laser synchronous signal does not enter within the specified period to the synchronous sensor PCB.
00002 The G laser synchronous signal does not enter within the specified period to the synchronous sensor PCB.
00003 The B laser synchronous signal does not enter within the specified period to the synchronous sensor PCB.
• For the diagnosis of the laser unit, perform Laser Self-Diagnostic. See ☞35950.
Adjustment failure point Manual No.
Adjustment failure in the attaching position of the interlock switch (printer top cover) -
Failed part Manual No.
Laser control PCB ☞66010
G-AOM driver
☞66080
Laser unit
☞63080
G laser driver
☞66070
Symptoms due to the wiring connection failure Symptoms of fuse blowout
☞4202 −−
