13/15
4. Troubleshooting
46000
46000
Error message: Printer 1
IMPORTANT
• Setup error. is shown on the display module.
On the maintenance application display, messages are shown.
Check Point
Diagnosis
NOTE
• To access the wiring diagrams, click Wiring diagrams in Bookmarks.
#0508 The target density setting value is out of allowable range when carrying out each setup. (G)
#0509 The target density setting value is out of allowable range when carrying out each setup. (B)
1 Calibrate the colorimeter.
2 Check that the calibration plate is not soiled.
Adjustment failure Manual No.
Adjust the colorimeter unit. ☞35100
Colorimeter failure Manual No.
Colorimeter unit failure
☞27460
Calibration plate failure
Failed part Manual No.
Laser control PCB
☞66010
G laser driver ☞66070
G-AOM driver ☞66080
Laser unit
☞63080
Suffix
number
Condition
