Frontier LP7700 - Page 62

2. Replacement and adjustment of parts
22000
3/3
22000
Magazine section
IMPORTANT
• If there is nothing wrong with the condition of reel plate and nut plate, and the reel plate's deflection is 0.3 mm
or more, replace the reel plate.
Dark room type magazine
Dark room type magazine
Reel plate, nut plate
Dents
Dark room type magazine
