5. Operation sequence
55230
4/5
55230
Paper advance operation
6. Paper supply pressure is released.
• Paper supply pressure change motor: ON (released)/OFF
When the paper supply pressure change sensor does not turn dark:
• ☞ No. 06134-00001
Paper Supply Pressure Change Motor operation error.
Note: The thick solid line indicates the paper.
Cut end sensor
Cut home sensor
Cut motor
G069966
Paper supply pressure change sensor
Paper supply pressure change motor
ote: The thick solid line indicates the paper.
G069967
