5. Operation sequence
55400
55400
Paper advance operation
6. Paper advance motor 2 changes its speed to high speed.
7. After paper advance motor 2 stops, paper advance unit 1 releases pressure.
• Paper advance motor 2: OFF
• Pressure guide motor: ON (released)/OFF
Paper advance motor 2
Pressure guide motor
G069837
Paper advance motor 2
Pressure guide motor
G069838
