5. Operation sequence
55430
2/2
55430
Paper advance operation
6. The paper rear end passed 130 mm from the exposure advance exit roller.
7. Paper advance unit 1 releases the pressure.
• Pressure guide motor: ON (released)/OFF
8. After pressure of paper advance unit 1 is released completely, paper advance motor 2 stops.
• Paper advance motor 2: OFF
Paper advance motor 2
Pressure guide motor
G069837
Pressure guide motor
G069838
