6. Electrical parts
66055
66055
Description of PCB (printer section)
TP4 IL+36 V voltage measurement Possible Not mounted
TP5 IL+24 V voltage measurement Possible Not mounted
TP6 Ground Possible Not mounted
TP7 DC+24 V voltage measurement Possible Not mounted
Fuse No. Rating Purpose Remarks
F55 T3.15 A/125 V Protection of IL+36 V
F56 T2.0 A/125 V Protection of IL+24 V
Test point No. Purpose Measurement with voltmeter Remarks
