6. Electrical parts
66800
66800
Explanation of PCBs (Processor section)
LED5, LED6 Unused
LED7 Interlock Switch (Replenisher Section Door): ON/OFF
check
ON
OFF
Test point No. Purpose Measurement with
voltmeter
Remarks
TP1 DC+24 V−A voltage measurement Possible
TP2 DC+24 V−B voltage measurement Possible
TP3 DC+5 V voltage measurement Possible
TP4G Ground Possible
TP5G DC+5 V Ground Possible
Fuse No. Rating Purpose
F60 T5 A/250 V PCB protection
LED No. Purpose Status
