BGS2T AT Command Set
11.22 Using GPRS AT commands (Examples)
BGS2T_ATC_V01.301 Page 337 of 554 1/31/12
c
EXAMPLE 2
Quality of Service (QoS) is a special parameter of a CID which consists of several parameters itself.
The QoS consists of
- the precedence class
- the delay class
- the reliability class
- the peak throughput class
- the mean throughput class
and is divided in "requested QoS" and "minimum acceptable QoS".
All parameters of the QoS are initiated by default to the "network subscribed value (= 0)" but the QoS itself is
set to be undefined. To define a QoS use the AT+CGQREQ or AT+CGQMIN command.
Overwrite the precedence class of QoS of CID 1 and set the QoS of CID 1 to be present:
A following read command will respond:
All QoS values of CID 1 are set to network subscribed now, except precedence class which is set to 2. Now
set the QoS of CID 1 to not present:
Once defined, the CID it can be activated. To activate CID 2 use:
If the CID is already active, the mobile responds OK at once.
If no CID and no STATE is given, all defined CIDs will be activated by:
If no CID is defined the mobile responds +CME ERROR: invalid index
Remark: If the mobile is NOT attached by AT+CGATT=1 before activating, the attach is automatically done by
the AT+CGACT command.
After defining and activating a CID it may be used to get online by:
The mobile supports Layer 2 Protocol (L2P) PPP only.
Remark: If the mobile is NOT attached by AT+CGATT=1 and the CID is NOT activated before connecting,
attaching and activating is automatically done by the AT+CGDATA command.
AT+CGQREQ=1,2
OK
AT+CGQREQ?
+CGQREQ: 1,2,0,0,0,0
OK
AT+CGQREQ=1
OK
AT+CGACT=1,2
OK
AT+CGACT=
OK
AT+CGDATA="PPP",1
CONNECT
The mobile is connected using the parameters of CID 1.
AT+CGDATA=
CONNECT
The mobile is connected using default parameters (<L2P>="PPP" and
<cid> as described for command AT+CGDATA).
