BGS2T AT Command Set

12.26 AT+FTM

BGS2T_ATC_V01.301 Page 366 of 554 1/31/12

12.26 AT+FTM Transmit Data

The AT+FTM command causes the TA to transmit data, using one of the modulation schemes defined in Section

12.1, FAX parameters.

An ERROR response code results if the write command is issued while the modem is on-hook. The test com-

mand can be used in on-hook or off-hook mode to check the modulation schemes supported by BGS2T.

Syntax

Notes

• Used for Fax Class 1 only.

• <mod>= 3 is not possible

Test Command

AT+FTM=?

Response(s)

(list of <mod>s)

Write Command

AT+FTM=<mod>

Response(s)

CONNECT

If error is related to ME functionality:

ERROR

PIN ASC0 MUX1 MUX2 MUX3  Last Reference(s)

- + + - - - - TIA/EIA-578

Confidential / Released

Default Chapter3
