BGS2T AT Command Set
17.3 AT^SBV
BGS2T_ATC_V01.301 Page 509 of 554 1/31/12
c
17.3 AT^SBV Battery/Supply Voltage
AT^SBV allows to monitor the supply (or battery) voltage of the module. The voltage is continuously measured
at intervals depending on the operating mode of the RF interface. The duration of a measurement period ranges
from 0.5s in TALK / DATA mode up to 50s when BGS2T is in IDLE mode or Limited Service (deregistered). The
displayed value is averaged over the last measuring period before the AT^SBV command was executed.
The measurement is related to the reference points of BATT+ and GND. For details on the reference points
please refer to the Hardware Interface Description [2].
Syntax
Parameter Description
Supply (or battery) voltage in mV
Test Command
AT^SBV=?
Response(s)
OK
ERROR
+CME ERROR: <err>
Exec Command
AT^SBV
Response(s)
^SBV: <value>
OK
ERROR
+CME ERROR: <err>
PIN ASC0 MUX1 MUX2 MUX3 Last
- + + + + + -
<value>
(num)
