BGS2T AT Command Set

4.4 AT&S

BGS2T_ATC_V01.301 Page 97 of 554 1/31/12

4.4 AT&S Set Data Set Ready (DSR) Line Mode

AT&S determines how the ME sets the DSR line depending on its communication state.

Syntax

Parameter Description

[0]

(&F)

DSR line is always ON

1 ME in command mode: DSR is OFF.

ME in data mode: DSR is ON.

Exec Command

AT&S[<value>]

Response(s)

PIN ASC0 MUX1 MUX2 MUX3  Last Reference(s)

- + + + + - - V.250

<value>

(num)(&W)(&V)

Confidential / Released
