BGS2T AT Command Set

12.5 AT+FCIG

BGS2T_ATC_V01.301 Page 345 of 554 1/31/12

12.5 AT+FCIG Query or set the Local Polling ID

Syntax

Parameter Description

Local Polling ID string, max. length and possible content as reported by test command. Default value is empty

string ("").

Notes

• Used for Fax Class 2 only.

• See also AT+FLID Query or set the Local ID setting capabilities.

Test Command

AT+FCIG=?

Response(s)

(max. length of Local Polling ID string) (range of supported ASCII character values)

Read Command

AT+FCIG?

Response(s)

<id>

Write Command

AT+FCIG=<id>

Response(s)

PIN ASC0 MUX1 MUX2 MUX3  Last Reference(s)

- + + - - - - EIA PN-2388

<id>

(num)
