BGS2T AT Command Set
14.7 AT^SXSM
BGS2T_ATC_V01.301 Page 415 of 554 1/31/12
c
14.7 AT^SXSM Extended SIM Access
AT^SXSM extends AT+CRSM with additional SIM commands.
All parameters of AT^SXSM are used as specified by 3GPP TS 11.11 [14]. BGS2T handles internally all required
SIM interface locking and file selection routines.
BGS2T may return error result code "+CME ERROR" if the command cannot be passed to the SIM, e.g. if no
SIM is inserted. However, errors related to SIM action are reported in <sw1> and <sw2> parameters as defined
in 3GPP TS 11.11 [14].
Syntax
Parameter Description
136 RUN GSM ALGORITHM
Start the authentication mechanism and cipher key generation on the SIM. It
runs the algorithms A3 and A8 using a 16 byte random number and the sub-
scriber authentication key Ki, which is stored in the SIM.
Identifier for an elementary data file on SIM, if used by <command>.
Parameter to be passed on by the BGS2T to the SIM.
Parameter to be passed on by the BGS2T to the SIM.
Parameter to be passed on by the BGS2T to the SIM.
If <command>=136 (RUN GSM ALGORITHM):
16 byte random number.
Test Command
AT^SXSM=?
Response(s)
OK
Write Command
AT^SXSM=<command>[, <fileID>[, <P1>, <P2>, <P3>[, <data>]]]
Response(s)
^SXSM: <sw1>, <sw2>[,<response>]
OK
ERROR
+CME ERROR: <err>
PIN ASC0 MUX1 MUX2 MUX3 Last
+ + + + + - -
<command>
(num)
<fileID>
(num)
<P1>
(num)
<P2>
(num)
<P3>
(num)
<data>
(str)
