BGS2T AT Command Set

12.13 AT+FDT

BGS2T_ATC_V01.301 Page 353 of 554 1/31/12

12.13 AT+FDT Data Transmission

This command requests the ME to transmit a Phase C page. When the ME is ready to accept Phase C data, it

issues the negotiation responses and the CONNECT result code to the application.

In Phase B, the AT+FDT command releases the ME to proceed with negotiation, and releases the DCS message

to the remote station. In Phase C, the AT+FDT command resumes transmission after the end of a data stream

transmitted before.

Syntax

Note

• Used for Fax Class 2 only.

Exec Command

AT+FDT

Response(s)

CONNECT

Write Command

AT+FDT=<df>, <vr>, <wd>, <ln>

Response(s)

CONNECT

PIN ASC0 MUX1 MUX2 MUX3  Last Reference(s)

- + + - - - - EIA PN-2388

Confidential / Released
