BGS2T AT Command Set

12.1 FAX parameters

BGS2T_ATC_V01.301 Page 340 of 554 1/31/12

Bit Rate

0 2400 bps, V.27ter

1 4800 bps, V.27ter

2 7200 bps, V.29

[3] 9600 bps, V.29

Data Compression Format

[0] 1-D modified Huffman

1 2-D modified read

2 2-D uncompressed mode

Error Correction Mode

[0] Disable ECM

1 Enable ECM, 64 bytes/frame

2 Enable ECM, 256 bytes/frame

Page Length

0 A4, 297mm

1 B4, 364mm

[2] Unlimited length

Scan Time/Line

[0] 0 ms (at VR= normal)

15 ms

210 ms

310 ms

420 ms

520 ms

640 ms

740 ms

Vertical Resolution

0 Normal, 98 lpi

[1] Fine, 196 lpi

<br>

(num)

<df>

(num)

<ec>

(num)

<ln>

(num)

<st>

(num)

<vr>

(num)

Confidential / Released
