BGS2T AT Command Set

13.13 AT+CSCA

BGS2T_ATC_V01.301 Page 391 of 554 1/31/12

13.13 AT+CSCA SMS Service Center Address

Write command updates the SMSC address, through which mobile originated SMs are transmitted. In text mode,

setting is used by send and write commands. In PDU mode, setting is used by the same commands, but only

when the length of the SMSC address coded into the <pdu> parameter equals zero.

Syntax

Notes

• In case of using no parameter after AT+CSCA= the content of <sca> will be deleted.

• This command writes the service center address to non-volatile memo.

• The SMS service center address should be entered as specified by the service provider.

Test Command

AT+CSCA=?

Response(s)

Read Command

AT+CSCA?

Response(s)

+CSCA: <sca>, <tosca>

Write Command

AT+CSCA=<sca>[, <tosca>]

Response(s)

PIN ASC0 MUX1 MUX2 MUX3  Last Reference(s)

+ + + + + - - 3GPP TS 27.005 [34]

Confidential / Released
