BGS2T AT Command Set
13.1 SMS Parameters
BGS2T_ATC_V01.301 Page 371 of 554 1/31/12
c
Message Reference
3GPP TS 23.040 [28] TP-Message-Reference in integer format
Originating Address
3GPP TS 23.040 [28] TP-Originating-Address Address-Value field in string format; BCD numbers (or GSM
default alphabet characters) are converted into characters; type of address given by <tooa>
Page Parameter
3GPP TS 23.041 [29] CBM Page Parameter bits 4-7 in integer format
Page Parameter
3GPP TS 23.041 [29] CBM Page Parameter bits 0-3 in integer format
In the case of SMS: 3GPP TS 24.011 [31] SC address followed by 3GPP TS 23.040 [28] TPDU in hexadecimal
format: ME converts each octet of TP data unit into hexadecimal numbers containing two IRA characters, e.g.
octet with integer value 42 is represented as two characters "2A", IRA 50 and 65 (decimal). In the case of CBS:
<ra> 3GPP TS 23.040 [28] TP-Recipient-Address Ad-dress-Value field in string format; BCD numbers (or GSM
default alphabet characters) are converted into characters; type of address given by <tora>
Recipient Address
3GPP TS 23.040 [28] TP-Recipient-Address Address-Value field in string format; BCD numbers (or GSM default
alphabet characters) are converted to characters of the currently selected TE character set (refer to command
AT+CSCS.); type of address given by <tora>
Service Center Address
3GPP TS 24.011 [31] RP SC address Address-Value field in string format; BCD numbers (or GSM default alpha-
bet characters) are converted to characters of the currently selected TE character set (AT+CSCS); type of
address given by <tosca>
Service Centre Time Stamp
3GPP TS 23.040 [28] TP-Service-Centre-Time-Stamp in time-string format (refer <dt>)
Serial Number
3GPP TS 23.041 [29] CBM Serial Number in integer format
<mr>
(num)
<oa>
(num)(+CSCS)
<page>
(num)
<pages>
(num)
<pdu>
(num)
<ra>
(num)(+CSCS)
<sca>
(num)(+CSCS)
<scts>
(num)
<sn>
(num)
