12.28 AT+FVRFC

BGS2T_ATC_V01.301 Page 368 of 554 1/31/12

12.28 AT+FVRFC Vertical Resolution Format Conversion

This command determines the DCE response to a mismatch between the vertical resolution negotiated for the

facsimile session and the Phase C data desired by the DTE.

Syntax

Parameter Description

0 Disable mismatch checking.

[2] Enable mismatch checking, with resolution conversion of 1-D data in the DCE,

and an implied AT+FK command executed on 2-D mismatch detection.

Note

• Used for Fax Class 2 only.

Test Command

AT+FVRFC=?

Response(s)

(list of supported <vrfc>s)

Read Command

AT+FVRFC?

Response(s)

<vrfc>

Write Command

AT+FVRFC=<vrfc>

Response(s)

PIN ASC0 MUX1 MUX2 MUX3  Last Reference(s)

- + + - - - - EIA PN-2388

<vrfc>

(num)

Confidential / Released

Default Chapter3
