BGS2T AT Command Set

12.16 AT+FLID

BGS2T_ATC_V01.301 Page 356 of 554 1/31/12

12.16 AT+FLID Query or set the Local Id setting capabilities

Syntax

Parameter Description

Local ID string

Max. length and possible content as reported by test command. Default value is empty string ("").

Notes

• Used for Fax Class 2 only.

• See also AT+FCIG.

Test Command

AT+FLID=?

Response(s)

(max. character length of Local ID string) (range of supported ASCII character values)

Read Command

AT+FLID?

Response(s)

<lid>

Write Command

AT+FLID=<lid>

Response(s)

PIN ASC0 MUX1 MUX2 MUX3  Last Reference(s)

- + + - - - - EIA PN-2388

<lid>

(num)
