BGS2T AT Command Set

19.3 Available AT Commands and Dependency on SIM PIN

BGS2T_ATC_V01.301 Page 526 of 554 1/31/12

AT+CRLP ø - - -

AT+CLCC + + ø ø

AT^SLCC + + + +

AT+CR ø + + +

AT+CRC ø - - -

AT+CSNS ø - - -

AT^SCNI + + ø ø

AT^SLCD + + ø ø

AT^STCD + + ø ø

ATP - ø ø ø

ATT - ø ø ø

ATS2 ø ø - -

twork Service Commands

AT+COPN + + ø ø

AT+COPS ø - ± ±

AT^SOPS ø - ø ø

AT^SRPN ø - - -

AT+CREG ø - - -

AT+CSQ - - ø ø

AT^SMONC + + ø ø

AT^SMOND + + ø ø

AT^MONI - - ø -

AT^MONP - - ø -

AT^SMONG + + ø +

AT^SALS ø + + +

AT^SHOM + + ø ø

AT^SPLM + + ø ø

AT+CPOL ø + + +

AT^SPLR ø + ø +

AT^SPLW ø + ø +

AT^SPCL ø - - -

AT^SNMON ø - ø -

pplementary Service Commands

AT+CACM ø + + +

AT^SACM + + ø +

AT+CAMM ø + + +

AT+CAOC + + + +

AT+CCUG ø + + +

AT+CCFC ø + ø +

AT+CCWA ø + + +

AT Command Exec Test Read Write
