- SV Series User’s Manual -
<Low-voltage Directive>
The precautions for the Low-voltage Directive are as follows:
• Overvoltage category: III
• Pollution degree: 2
In addition to the conditions above, be sure to install a fuse for the main circuit power supply.
■ KC Certificate (South Korea)
The SV Series has received KC certification.
Class A Equipment
This is a class A product. In a domestic environment this product may cause
radio interference in which case the user may be required to take adequate measures.
A급 기기 (업무용 방송통신기자재)
이 기기는 업무용(A급) 전자파적합기기로서 판매자 또는 사용자는 이 점을주의하시기 바라며, 가정외의 지역에서 사
용하는 것을 목적으로 합니다.
■ Precautions for UL certification
• Applicable standards
The precautions for the UL certification are as follows:
• Pollution degree: 2
• Power supply environment with short-circuit current of 5,000 A or less.
• Wiring processed with the maximum tightening torque described in the SV Series User's Manual.
• This product does not provide motor over-temperature sensing. External motor over-temperature protection is
required as defined in NFPA70: 2011 Edition of the National Electrical Code, Article 430, Section X, Paragraph
430.126.
• This product requires installation of Branch Circuit Protection (BCP) as defined in NFPA70: 2011 Edition of the
National Electrical Code,Article 430, Section IV, Paragraph 430.52.
• Installation of a fuse or of a circuit breaker according to the NFPA70 (NEC).
* Duration of the incoming current is 20 ms at maximum.
Fuse or circuit breaker on the main power supply must be the UL certified one.
The above power supply capacity and incoming current are approximate values.
Model UL standard (UL File No.)
Servo amplifier
SV
UL508C (E231699) CSA C22.2 No.14
Servo motor UL1004 (E223442) CSA C22.2 No.100
Main
circuit
voltage
Model
SV-
Capacity
(W)
Power supply
capacity
per unit
(kVA)
Current capacity Incoming current
Main
circuit
(Arms)
Control
circuit
(Arms)
Main
circuit
(A)
Control
circuit
(A)
Single-phase
100 VAC
005150 0.2 1.5
0.38 16.5 35
0101 100 0.3 2.5
0201 200 0.7 5
0401 400 1.4 10
3-phase
200 VAC
0052 50 0.2 1.0
0.2
33
70
0102 100 0.3 1.0
0202 200 0.6 2.0
0402400 1 3.0
0752 750 1.6 6.0
33
1002 1.0 k 2.3 6.0
1502 1.5 k 3.2 7.3
0.252002 2.0 k 4.0 9.7
3002 3.0 k 5.9 15
5002 5.0 k 7.5 25 0.2 65.5

Keyence SV Series Specifications

General

Display	LCD
Output Type	Digital, Analog
Power Supply	24V DC
Communication	Ethernet, RS-232, RS-485
Series	SV Series
Programming Language	Ladder Logic
Mounting	Panel mounting
Operating Temperature	0 to +50°C
Storage Temperature	-20 to +60°C
Vibration Resistance	10 to 55 Hz
Shock Resistance	30G
