- SV Series User’s Manual -
Use a cable that satisfies the following ratings and structures.
• Wire range: Refer to the SV Series AC Servo System User's Manual.
• Wire type: Single or stranded wire (The SV-500∗2 is stranded wire only)
• Wire material: Copper
• Rated temperature: 75°C max.
Note that some servo amplifiers are required to satisfy the following restrictions.
For wiring of the SV-500∗2 type to the following terminals, use special crimping terminals, sleeves, and the terminal kit
(included with the SV-500∗2).
Model of servo amplifier Restrictions
SV-3002 Use a wiring circuit breaker with a current rating of 40 A or less.
SV-5002
Use fuses with the following current rating.
Non-time-delay fuse: 70 A or less.
Time-delay fuse: 40 A or less.
Terminal names
Crimping terminal models
(JST Mfg. Co., Ltd.)
Sleeve models
(Tokyo Dip co., ltd.)
Control circuit power supply terminal (L1C,
L2C)
R1.25-4 (2) TP-003 (Black) (2)
DC reactor connection terminal ( 1, 2) 5.5-4NS (2) TP-006 (White) (2)
Motor power supply connection terminal 8-4NS (3) TP-014 (Black) (3)
Ground terminal R2-4 (2) —
