11-3 List of Display Items in Access Window
- SV Series User’s Manual -
ACCESS WINDOW
*2 ◎ : Always displayed.
○ : Displayed when display level is set to "All" or "Basic and extend".
(without a mark): Displayed when display level is set to "All".
*3 Displayed only for the MECHATROLINK-II type servo amplifier.
Main menu Submenu MECHATROLINK-II type
3. Parameter ML-2
*3
Parameter *2
ML_10 1stDecRate 1 (x10kC_P/s2)
ML_11 2ndDecRate 1 (x10kC_P/s2)
ML_12 DcRateSWSpd1 (x100C_P/s)
ML_13 AccDecBias (x100C_P/s)
ML_14 AccDecConst (x0.1ms)
ML_15 MoveAvgTime (x0.1ms)
ML_16 DstAftrLtch
ML_17 Origin Dir
ML_18 OrgCreepSpd1 (x100C_P/s)
ML_19 OrgCreepSpd2 (x100C_P/s)
ML_20 OrgDstAftrLt (CMD_PLS)
ML_21 P-LtchArea (CMD_PLS)
ML_22 N-LtchArea (CMD_PLS)
ML_23
DecConst 1 (x10kC_P/s2)
ML_24 *AccDecRate
ML_25 1stAccRate 2 (x10kC_P/s2)
ML_26 2ndAccRate 2 (x10kC_P/s2)
ML_27 AcRateSWSpd2 (CMD_PLS/s)
ML_28 1stDecRate 2 (x10kC_P/s2)
ML_29 2ndDecRate 2 (x10kC_P/s2)
ML_30 DcRateSWSpd1 (CMD_PLS/s)
ML_31
DecConst 2 (x10kC_P/s2)
ML_32 LatchNum
ML_33 ContLtchCnt
ML_34 LatchSig 1
ML_35 LatchSig 2
ML_36 LatchSig 3
ML_37 LatchSig 4
ML_38 LatchSig 5
ML_39 LatchSig 6
ML_4 0 LatchSig 7
ML_41 LatchSig 8
ML_42 IO12 Monitor
ML_42 IO13 Monitor
ML_44 IO14 Monitor
ML_45 IO15 Monitor
ML_46 OptionMon 1
ML_47 OptionMon 2
ML_48 *OPTIONField
ML_49 *ACCFIL Pos
ML_50 *ACCFIL
ML_51 *G_SEL Pos
ML_52 *G_SEL
ML_53 *V_PPI Pos
ML_54 *V_PPI
ML_55 *P_PI_CLRPos
ML_56 *P_PI_CLR
ML_57 *P_CL Pos
ML_58 *P_CL
ML_59 *N_CL Pos
ML_60 *N_CL
ML_61 *BANK_SEL1Ps
ML_62 *BANK_SEL1
ML_63 *LT_DIS Pos
ML_64 *LT_DISABLE
ML_65 *OUT_SIG Pos
ML_66 *OUT_SIGNAL
ML_67 ML ChkMask
ML_68 WarnChkMask
ML_69 *PosTFF/TLIM
ML_70 SvoffWaitT (x10ms)
To Next Page
