4-18
SIGNALS AND WIRING
4
4-4 Wiring Servo Motor
- SV Series User’s Manual -
● Encoder connector kit (1kW to 5kW)
● Motor power connector kit (1kW to 5kW)
● Electromagnetic brake connector kit (1kW to 5kW)
(4) Encoder connector
(Servo amplifier side)
(5) Encoder connector
(Servo amplifier side)
(6) Motor power connector
(7) Electromagnetic brake connector
