Diagnostic information 2-45
4024-XXX
244.00 Sensor (tray 4 feed-out) on jam (tray 4 media feed)
2 Check the sensor (tray 3 feed-out) for proper operation.
1. Enter Diagnostics mode.
2. Select INPUT TRAY TESTS.
3. Select Sensor Tests.
4. Select Tray 3.
5. Select Feed-out.
Open the 2TM/TTM left door assembly, and visually
check it.
Does the display on the operator panel change every
time the actuator on the above sensor operates?
Go to step 4. Go to step 3.
3 Check the sensor (tray 3 feed-out) for proper
connection.
Is the above sensor connected properly?
Replace the sensor
(tray 3 feed-out).
Go to “2000-sheet
dual input (TTM)—
sensor (tray 3 feed-
out) removal” on
page 4-89.
Replace the
connection.
4 Perform a print test.
Does the error still occur?
Replace the 2TM/
TTM controller card
assembly.
Go to “2000-sheet
dual input (TTM)—
2TM/TTM controller
card assembly
removal” on
page 4-116.
Go to step 5.
Problem solved.
5 Perform a print test.
Does the error still occur?
Replace the printer
engine card
assembly.
Refer to the Printer
Service Manual.
Problem solved.
Step Check Yes No
1 Check the media condition.
Is the media in the tray crumpled or damaged?
Replace the media. Go to step 2.
2 Check the media size setup.
Does the media size in use match the size set for tray
4?
Go to step 3. Replace the media
or change the media
size setup.
Step Check Yes No
