Lexmark W840 - HCF Left Cover Removal; HCF Rear Cover Removal

4-124 Options Service Manual
4024-XXX
HCF left cover removal
1. Remove the five screws securing the HCF left cover (A) to the unit.
2. Remove the HCF left cover (A).
HCF rear cover removal
1. Remove the four screws securing the HCF rear cover (A) to the unit.
2. Remove the HCF rear cover (A).
A
A
