Lexmark W840 - 500-Sheet Drawer (2 TM)-Left Cover Removal; 500-Sheet Drawer (2 TM)-Rear Cover Removal

Repair information 4-5
4024-XXX
2X 500-sheet drawer (2TM)—left cover removal
1. Remove the two screws securing the left cover (A).
2. Remove the left cover (A).
2X 500-sheet drawer (2TM)—rear cover removal
1. Remove the four screws securing the rear cover (A).
2. Remove the rear cover (A).
A
Left
Rear
A
