Lexmark W840 - 500-Sheet Drawer (2 TM)-Switch (2 TM;TTM Left Door Interlock) Removal

4-42 Options Service Manual
4024-XXX
2X 500-sheet drawer (2TM)—switch (2TM/TTM left door interlock) removal
1. Open the 2TM/TTM left door assembly.
2. Remove the one screw securing the bracket (A).
3. Disconnect the connector from the switch (2TM/TTM left door interlock) (B).
4. Release the hooks securing the switch (2TM/TTM left door interlock) (B) to the bracket (A).
5. Remove the switch (2TM/TTM left door interlock) (B).
B
Left
A
