Lexmark W840 - Duplex Media in Actuator Removal

Repair information 4-175
4024-XXX
Duplex media in actuator removal
1. Remove the duplex unit assembly. See “Duplex unit assembly removal” on page 4-154.
2. Remove the two screws securing the duplex lower guide (A) to the duplex unit assembly.
3. Remove the duplex lower guide (A).
A
Right
