Lexmark W840 - Exit 2 Switch (Exit 2 Left Door Interlock) Removal

4-202 Options Service Manual
4024-XXX
Exit 2 switch (exit 2 left door interlock) removal
1. Remove the exit 2 unit assembly. See “Exit 2 unit assembly removal” on page 4-192.
2. Open the exit 2 unit assembly.
3. Remove the exit 2 left cover. See “Exit 2 left cover removal” on page 4-197.
4. Remove the exit 2 right cover. See “Exit 2 right cover removal” on page 4-198.
5. Release the hooks securing the switch (exit 2 left door interlock) (A) to the exit 2 unit assembly.
6. Remove the switch (exit 2 door interlock) (A).
Harness
Guides
Front
A
