3-28 Options Service Manual
4024-XXX
Driving force transmission path
Transport motor
The rotating force of the transport motor is transmitted through the gear and the pulley (25 tooth) to components
that need mechanical driving force as shown in the following diagram.
The driving force transmitted to the gear drives the transport roll assembly, multipurpose feeder (MPF) feed roll,
registration roll assembly, fuser assembly, and exit 1 media exit roll assembly through the clutch and gears.
The driving force transmitted to the pulley (25 tooth) drives the exit 1 media exit roll assembly through the gears.
The driving force transmitted to the fuser assembly drives the heat roll.
PC cartridge motor
The rotating force of the PC cartridge motor is transmitted through the gears to components that need a
mechanical driving force as shown in the following diagram.
The driving force transmitted to the PC cartridge drives the drum. The driving force is then transmitted to the
transfer roll assembly by direct contact with the drum.
Media transport motor
Transport/MPF idler gear 21T/21T
Transport Clutch
Vertical gear drive ASM
Gear18T
Transport
roll ASM
MPF feed
roll ASM
Registration
roll ASM
Fuser unit
ASM
Exit1 media
exit roll
ASM
Gear19T
Gear exit
Pulley25T
PC cartridge motor
Drum
Transfer roll
Magnetic Roll
