Lexmark W840 - HCF Media out Actuator Removal

4-138 Options Service Manual
4024-XXX
HCF media out actuator removal
1. Open the HCF top door.
2. Open the HCF feed unit assembly.
3. Remove the e-clip securing the media out actuator (A) to the HCF media feed unit assembly (B).
4. Remove the media out actuator (A).
A
B
E-ring
