Component locations 5-3
4024-XXX
TTM components
2TM/TTM clutch assembly
2TM/TTM drive motor
2TM/TTM controller
card assembly
Sensor (tray 4 feed out
Sensor (tray 3 feed out)
witch (2TM/TTM left
oor interlock)
Sensor (pre-feed)
Sensor (media level)
Sensor (media out)
Switch (TTM media siz
