Repair information 4-57
4024-XXX
2000-sheet dual input (TTM)—tray 3 front cover removal
1. Pull out the tray 3 assembly.
2. Remove two screws securing the tray 3 front cover (A) to tray 3 assembly (B).
3. Remove the tray 3 front cover (A).
A
B
