Lexmark W840 Service Manual

Diagnostic information 2-81
4024-XXX
No media in the select media tray
7 Perform a print test.
Does the error still occur?
Replace the HCF
controller card
assembly.
Go to “HCF
controller card
assembly removal”
on page 4-152.
Go to step 8.
Problem solved.
8 Perform a print test.
Does the error still occur?
Replace the printer
engine card
assembly.
Refer to the Printer
Service Manual.
Problem solved.
Step Check Yes No
1 Check the media.
Is the media loaded in the selected tray?
Go to step 2. Load media.
2 Check the sensor (media out) for proper operation.
1. Enter Diagnostics mode.
2. Select INPUT TRAY TESTS.
3. Select Sensor Tests.
4. Select Tray 5.
5. Select Media out.
Pull the HCF unit away from the printer, open the HCF
top door, and open the HCF feed unit.
Does the display on the operator panel change every
time the sensing area on the above sensor is blocked by
the media out actuator.
Go to step 4. Go to step 3.
3 Check the sensor (media out) for proper connection.
Is the above sensor connected properly?
Replace the sensor
(media out).
Go to “HCF sensor
(media out)
removal” on
page 4-140.
Replace the
connection.
4 Check the HCF controller card connection PF103 and
the HCF hookup connection on the rear of the printer.
Are the connections listed above connected properly?
Go to step 5. Replace the
connection.
5 Perform a print test.
Does the error still occur?
Replace the HCF
controller card
assembly.
Go to “HCF
controller card
assembly removal”
on page 4-152.
Go to step 6.
Problem solved.
Step Check Yes No

Lexmark W840 Specifications

General

Color	No
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	6.8 s
Print speed (black, normal quality, A4/US Letter)	50 ppm
Internal memory	256 MB
Sound power level (standby)	28 dB
Sound pressure level (printing)	54 dB
Total input capacity	1100 sheets
Total output capacity	500 sheets
Maximum input capacity	5100 sheets
Display	LCD
Maximum print size	297 x 420 mm
Media types supported	Plain paper, envelopes, card stock, transparencies, paper labels
Media weight (tray 1)	Plain paper: 64 to 216 g/m2; Card stock: up to 199 g/m2 Index
Maximum ISO A-series paper size	A3
Page description languages	PDF 1.5, PPDS
I/O ports	USB, Parallel, 1 internal solutions port (ISP)
Mac compatibility	Yes
Compatible operating systems	Windows, Linux, UNIX, Mac, NetWare and OS/400
Recommended operating temperature range (T-T)	16 - 32 °C
Sustainability certificates	ENERGY STAR
Power consumption (standby)	9 W
Power consumption (printing)	700 W
Power consumption (PowerSave)	105 W
Bundled software	MarkVision Professional
Operating relative humidity (H-H)	8 - 80 %

Weight and Dimensions

Dimensions (WxDxH)	616 x 520 x 475 mm
