Repair information 4-87
4024-XXX
11. Remove three screws securing the media feed unit assembly (D).
12. Remove the media feed unit assembly (D) by pulling outward.
13. Remove two screws securing the rear bracket (E) to the media feed unit assembly (D).
14. Remove the rear bracket (E).
Front
Connector
Clamps
E
Connector
D
